COMS Barcode Scanner QR Code Reader Security System
RCQ-733 yog barcode scanner nrog kev daws teeb meem txog 1280 * 800. Cov cuab yeej no muaj lub teeb xiav LED uas flashes thaum luam theej QR cov lej. Nws hnyav tsuas yog 65 grams thiab tuaj yeem siv rau ntau qhov chaw. Lub zog yuav tsum tau ua haujlwm ntawm RCQ-733 barcode scanner yog 300mW thiab cov khoom siv hluav taws xob yog 5V DC.
Peb qhia peb cov txheej txheem scanner qib siab, tsim los hloov koj cov kev paub scanning, nrog kev daws teeb meem zoo txog li 1280 * 800. Nruab nrog siab - kev daws teeb meem imaging peev xwm, qhov module no ua kom pom tseeb thiab raug. bars tseem ceeb.
Nta:
Kev daws teeb meem siab: Txaus siab rau siv lead ua - scanning meej nrog kev daws teeb meem txog 1280 * 800, ntes txawm tias cov ntsiab lus me tshaj plaws ntawm barcodes.
Kev Ua Haujlwm Zoo Tshaj Plaws: Kev paub nrawm thiab raug kuaj xyuas, txhawb kev ua haujlwm zoo thiab tsim khoom hauv koj cov haujlwm.
Versatile Compatibility: Seamlessly integrate no module rau hauv koj lub tshuab, txhim khu koj workflow nrog nws saj zawg zog compatibility.
Tsim kom ntev ntev: Ua kom kawg, qhov qauv no muaj kev tsim kho kom ruaj khov, ua kom muaj kev ntseeg siab thiab siv tau ntev hauv ntau qhov chaw.
Txhim Kho Kev Ua Haujlwm: Xauv qib tshiab ntawm kev muaj peev xwm luam theej duab nrog cov qauv no, zoo meej rau ntau hom kev xav tau scanning.
Daim ntawv thov
· Kev Tswj Xyuas Khoom Muag Khoom Muag
· Kev koom ua ke kev noj qab haus huv
· Kev Tswj Xyuas Zoo
· Logistics thiab Shipping Optimization
· Kev Ticketing thiab Access Control
Specification
|
Cov duab sensor |
CMOS |
|
|
Kev daws teeb meem piv |
1280 * 800 (Full exposure) |
|
|
Interface |
USB |
|
|
Nyeem CodeSystem |
2D |
MicroQR, PDF417, QR Code, DataMatrix, Aztex, Maxicode |
|
|
1D |
Code128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, |
|
Kev nyeem ntawv raug |
5mil ua |
|
|
Teeb pom kev zoo |
Dawb LED |
|
|
Rotational rhiab heev |
Kov |
360 degree |
|
|
Lean |
± 50 degree |
|
|
Deflection |
± 50 degree |
|
Cim contrast * |
Ntau dua lossis sib npaug li 30% |
|
|
Teb kaum |
Qib |
49 degree |
|
|
Ntsug |
37 degree |
|
ApplicationEnvironment |
EAN 13 |
55mm-230mm (13mil) |
|
|
QR |
35mm-170mm (15mil) |
|
|
Cov ntaub ntawv Matrix |
40mm-115mm (20mil) |
|
|
ib 417 |
40mm-110mm (6.67mil) |
|
|
QRCode |
40mm-410mm (32mil) |
