Phau ntawv Insertuin IC & RF Smart Card Reader Hlau Bezel

Phau ntawv ntxig hlau bezel IC & RF daim npav nyeem ntawv nrog RS232 interface yog ntau yam cuab yeej tsim los kom ruaj ntseg thiab ua tau zoo nyeem daim npav. Nws txhawb nqa ob daim npav IC (raws li ISO7816) thiab RF phaib (ua raws li ISO14443A&B cov qauv), ua rau nws tsim nyog rau ntau yam kev siv, suav nrog kev tswj xyuas, kev them nyiaj, thiab kev txheeb xyuas tus kheej.

Hauj lwm lawm

Kev tsis

Phau ntawv Insertuin IC & RF Smart Card Reader Hlau Bezel

Lub thav duab hlau ruaj khov ua kom ntev - siv tau ntev thiab ua haujlwm zoo.

Cov kev sib txuas sib txuas rau kev sib txuas lus software yog RS232, TTL thiab USB.
Nws compact loj ntawm 92.3mm x 78mm x 18mm ua rau nws yooj yim rau nruab rau hauv ib qho kev teeb tsa.
Kev xa cov ntaub ntawv ceev thiab raug yog qhov zoo tagnrho rau cov neeg nyeem daim npav uas muaj kev ntseeg siab thiab ruaj ntseg.
Ua tau raws li cov qauv Ua raws li cov qauv thoob ntiaj teb rau IC thiab RF daim npav nyeem ntawv.
Manual Input Design Ua kom cov neeg siv kev paub dhau los thiab kev nyab xeeb ua haujlwm.
Lub siab -kev tsim qauv tuaj yeem tiv taus kev ua haujlwm siab thiab zaus.

QQ20250718-152532

product-992-911

Ntsiab Feature

Hauv cov ntsiab lus, hlau -framed IC & RF daim npav nyeem ntawv nrog phau ntawv pub yog ib qho kev txhim khu kev qha thiab muaj zog rau cov ntawv pov thawj hauv RS232 interface. Kev sib txuas ceev thiab yooj yim, nws txhawb nqa ob daim npav IC thiab RF, ua rau nws zoo tagnrho rau kev tswj xyuas, kev them nyiaj, thiab kev lees paub. Nws cov thav duab steel ruaj khov, tsim qauv zoo nkauj, thiab kev sib txuas sib txawv kom ntseeg tau tias nws haum seamlessly rau txhua qhov chaw. Tsim los rau kev ua tau zoo thiab lub neej ntev, tus nyeem ntawv ua kom nrawm thiab raug hloov pauv rau cov qauv thoob ntiaj teb - zoo tagnrho rau lub hom phiaj- cov ntawv thov tseem ceeb.

QQ20250718-152607

hezuohuoban

Cim npe nrov: phau ntawv insertuin ic&rf ntse card nyeem ntawv hlau bezel, Tuam Tshoj, manufacturers, lwm tus neeg, Hoobkas, customized, pheej yig, tej, luv nqi, hauv Tshuag

Voltage input	DC 5.0 ± 5% V / USB fais fab mov
Kev siv tam sim no	Static tam sim no:< 50mA Peak tam sim no:< 200 mA
Interface	RS-232 tus qauv serial chaw nres nkoj / USB2.0 interface
Daim npav Specification	Dav: 53.92 ~ 54.18mm, Ntev: 85.47 ~ 85.90mm Thickness: 0.76 ~ 1mm (Ex- ua haujlwm txheem 0.76mm)
Lub neej	Micro Hloov: 500,000 zaug IC card down force device thiab IC hu rau: 300,000times
Tus nqi yuam kev	IC daim npav: nyeem / sau daim npav 1000 zaug, tus nqi yuam kev<1times(except dirty card causes error)
MTBF	>100,000hours (tsuas yog cov khoom siv hluav taws xob) Nco tseg: 250 zaug / txhua hnub, 25 hnub / txhua hli, 300hours / txhua lub hli.
Environmental mob	Kev ua haujlwm: -20ºC ~ 50ºC, 0 ~ 90% RH (Non-condensing). Cia: -25ºC ~ 80ºC, 0 ~ 95% RH (Non-condensing).
Kev ntseeg tau	Kev vibration: Ntau zaus: 5 ~ 50Hz; Ceev ceev: 2m / s2 (0.2g), Kev vibration kev taw qhia thiab lub sijhawm: mus rau X, Y, Z. txhua qhov kev taw qhia rau 15 feeb. Amplitude: 2 hli; tag nrho cov haujlwm tsis raug cuam tshuam tom qab vibration. B. Kev poob siab: 294m / s2 (30g), 11ms, ib zaug rau txhua qhov kev taw qhia X, Y, Z. tag nrho cov haujlwm tsis raug cuam tshuam tom qab poob siab.(tsis muaj pob ntawm daim npav nyeem ntawv).
Online download tau	Txhawb ISP online rub tawm.
Net nyhav	Approx: 0.2 Kg (tsis muaj accessories)
ROHS tus qauv	Ua raws li ROHS tus qauv.
IC daim npav tus qauv	Ua raws li ISO7816 tus qauv, Piv txwv li: (AT24C01,24C02,……,24C256;SLE4442,SLE4428;CPU T=0/T=1).
